Microscopic research on the olfactory organ of the Far Eastern brook lamprey Lethenteron reissneri (Pisces, Petromyzontidae)
Applied Microscopy volume 50, Article number: 18 (2020)
The olfactory anatomy and histology of Lethenteron reissneri were researched using a stereo microscope, a light microscope, and a scanning electron microscope. As in other lampreys, it shows same characters as follows: i) a single olfactory organ, ii) a single tubular nostril, iii) a single olfactory chamber with gourd-like form, iv) a nasal valve, v) a nasopharyngeal pouch, vi) a sensory epithelium (SE) of continuous distribution, vii) a supporting cells with numerous long cilia, viii) an accessory olfactory organ. However, the description of a pseudostratified columnar layer in the SE and Non SE is a first record, not reported in sea lamprey Petromyzon marinus. In particular, both 19 to 20 lamellae in number and olfactory receptor neuron’s quarter ciliary length of the knob diameter differ from those of P. marinus. From these results, it might be considered that the olfactory organ of L. reissneri shows well adaptive structure of a primitive fish to slow flowing water with gravel, pebbles, and sand and a hiding habit into sand bottom at daytime. The lamellar number and neuron’s ciliary length may be a meaningful taxonomic character for the class Petromyzonida.
In fishes, the olfactory organ is an essential chemoreceptor that processes smells and deeply related to diverse ecological behaviors: prey detection, feeding, reproduction, predator risk avoidance, home recognition and migration (Hara 1986). This organ also is a good morphological indicator to reflect aquatic habitat conditions: i) a degree of water volume, a velocity, a turbidity, and a bottom structure as physical factors (Kim et al. 2019) and ii) pH, infective pathogens, hazard materials, and types of chemical odors as chemical factors (Ghosh and Mandal 2014) and iii) fish’s ecology (Yamamoto 1982). Finally, the above factors may lead the olfactory organ to have some modification in morphology, rosette structure, lamellar number and arrangement, and sensory epithelial distribution (Yamamoto 1982; Zeiske et al. 1992; Kasumyan 2004). So far, fish’s olfactory researches have mainly focused on the higher vertebrate group. The lower lineage, especially the cyclostomata, has not been known well (Kasumyan 2004; Ferrando et al. 2019; Ren et al. 2009).
The cyclostomata is the most primitive vertebrate, and consist of the two classes, Petromyzonida (lamprey) and Myxini (hagfish) (Yang et al. 2016). Among them, lamprey retains strong resemblance to a fossil organism that has early vertebrate characters (Gess et al. 2006), so that they have been highlighted as a best model for studying the embryonic development, evolution, and organ differentiation of fish taxa (Yang et al. 2016). Lamprey has currently recognized 38 species (Docker 2006), most of which are parasitic and carnivorous to feed blood other fishes and migrate from saltwater to freshwater (Hardisty 2013). Some are non-carnivorous species to live exclusively in freshwater (Potter et al. 2015). Meanwhile, anadromous and landlocked Atlantic salmon showed physiological and histological differences in acclimation to seawater, i.e. the anadromous fish has larger chloride cells of the gill in size and more activated Na+, K+ ATPase than landlocked fish (Nilsen et al. 2007). So far, the olfactory research of lamprey, however, has only been focused on anadromous saltwater species (Kleerekoper and Erkel 1960; Van Denbossche et al. 1995, 1997; Ren et al. 2009). With the non-anadromous and landlocked fish, Lethenteron reissneri, therefore, anatomical and histological studies on the olfactory organ was carried out, particularly with regard to ecological adaptation.
Materials and methods
Ten adult lamprey L. reissneri (124.2 to 166.5 mm in standard length, SL; Fig. 1a) were caught by a scoop net (4 × 4 mm in mesh) in June 2017 in the stream of Daegi-ri, Sandong-myeon, Namwon-si, Jeollabuk-do, South Korea (Fig. 1b). Among the total ten specimens collected, five were fixed in 10% formalin solution buffered at pH 7.4 (0.2 M phosphate buffer) and the rest were taken to the laboratory for two steps of fixing process by 2.5% glutaraldehyde solution (G.A. solution) buffered at pH 7.4 (0.2 M phosphate buffer). For catching the fish, we received a permission allowed by the ministry (a license number: No. 2017–18). All procedures for this study were performed according to the rules under Jeonbuk National University Institutional Animal Care and Use Committee.
For checking gross structure, the olfactory organ was anatomized using a blade (Feather Safety Razor Co., LTD, Japan) under a stereo microscope (SM; Stemi DV4, Carl Zeiss, Germany), and photographed with a digital camera (TG-3, Olympus, Japan).
A light microscope (LM, Carl Zeiss, Germany) and a scanning electron microscope (SEM, Carl Zeiss, SUPRA40VP, Germany) were used for identifying the cells and the organization of the olfactory epithelium. For histological investigation of the olfactory epithelium, the olfactory tissue was dissected out from the head of the fixed specimens, dehydrated in an ascending ethanol series (50%, 60%, 70%, 80%, 90%, 95%, 100%), cleared in the solution of a one xylene to one 100% ethanol mixed ratio and absolute xylene, and then embedded in paraffin wax (Paraplast, Oxford). 5 μm sections were deparaffinized and then stained with hematoxylin and eosin (H&E) and Masson’s trichrome (Gurr 1956) for general histology. For the surface observation of the olfactory epithelium, the lamellae were dissected out from the head of fixed specimens and fixed again in 2.5% G.A. solution for 24 h. Then the olfactory tissue were fixed in 1% osmium tetroxide solution with 0.1 M phosphate buffer, and dehydrated by a graded series of ethanol, and dried using a t-BuOH freeze dryer (VFD-21S, Vacuum Device Co., Ltd., Ibaragi, Japan). The dried samples were coated with osmium tetroxide by ion sputtering (HPC-1SW, Vacuum Device Inc., Tokyo, Japan) and then observed under the SEM.
At the top of the head, the single olfactory organ of L. reissneri consists of the single nostril, and single olfactory chamber, and single nasopharyngeal pouch (Fig. 2). The single nostril (0.6 to 1.1 mm in major diameter; 0.2 to 0.4 mm in major length) forms a tube shape projecting from the skin surface (Fig. 2b and c). The single olfactory chamber is a gourd-like form and has 19 to 20 lamellae with a longitudinal arrangement on the lateral wall. It is linked proximally with the nasopharyngeal pouch. The nasopharyngeal pouch forms an elongated canal that is expanding toward the caudal direction and closed (Fig. 2a).
In a light micrograph, the olfactory organ of L. reissneri is classified into the main olfactory organ (MOO) and accessory olfactory organ (AOO). The MOO contains several lamellae at the lateral wall of the olfactory chamber that is surrounded by the cartilaginous tissue. The lamellae with different size consist of the sensory (SE) and non-sensory (NSE) epitheliums, respectively. The fila olfactoria with abundant axons are present under the epithelial layer (Fig. 3a and b). The SE in both sides of the lamellae shows a continuous type in its distribution. In contrast, the NSE occurs only in the top region of lamellae and in the epithelial region between the lamellae (Fig. 3a and b). The SE of a pseudostratified columnar layer has olfactory receptor neurons (ORN), supporting cells (SC), and basal cells (BC) (Fig. 3c and d). The ORNs are a bipolar cell with two extensions. They show a scarlet nucleus stained with H&E and thick violet with Masson’s trichrome. The SCs are a cylindrical cell, stained more weakly than those of the ORNs with H&E staining and Masson’s trichrome staining, and contains an oval nucleus at the middle part of the epithelium. The BCs are placed vertically at the bottom of the SE. They are absent of any extending branches and has a little cytoplasm. The NSE of a pseudostratified columnar layer is composed of columnar epithelial cells (CEC) and plasma cells (PC) (Fig. 3e and f). The CECs are a large cylindrical cell with numerous cilia at its surface, and show nucleus’s different position arranged to two layers. The large nucleus stains weak scarlet with H&E and has the single prominent nucleolus at the center. The PCs are a small cell and has one-sided nucleus in the cell body. The cytoplasm are stained deep red with Masson’s trichrome.
The AOO is the aggregation of tubular epithelial vesicles that are distributed in fila olfactoria, the connective tissue (Fig. 3g). The epithelium is a simple cuboidal layer that only consists of cuboidal epithelial cells (CC). The CCs have a nucleus with centered nucleolus and little cytoplasm. They are a weak purple stained with H&E (Fig. 3h).
Ultrastructure of the olfactory epithelial surface
The MOO’s epithelia show the three contents: ORN’s knob, SC’s long cilia, and a mucous mass (Fig. 4a and b). The ORN’s knob bears five to eight short cilia on its surface (Fig. 4a) and shows an elongated narrow body extending to the surface as in a light microscopy (Fig. 4c). The length of their cilia is about 0.2–0.5 μm, a quarter of the knob’s diameter (Fig. 4a). Long cilia are intertwined for each other and some are curling with mucus mass (Fig. 4d).
L. reissneri shows the unpaired olfactory organ unlike the jawed vertebrates, Osteichthyes and Chondrichthyes, having paired structures at both sides of the snout (Kasumyan 2004). The position of the jawed vertebrate’s olfactory organ was general at the ventral part of the snout in Chondrichthyes and at the dorsal part of the snout in Osteichthyes (Zeiske et al. 1992). Interestingly, however, that of L. reissneri is located at the top of the head. Of the same cyclostomata, lamprey has the same position to that of L. reissneri (Kleerekoper and Erkel 1960) but hagfishes are above the oral cavity (Theisen 1973, 1976). Such top positions of the olfactory organ in L. reissneri as well as in other lampreys may reflect their phylogeny as representative of the lower taxa, not higher taxa such as teleost.
The olfactory organ of L. reissneri is characterized by a tube form of single nostril, a single gourd-like chamber, a nasal valve, a nasopharyngeal pouch, a longitudinal arrangement of lamellae, a continuous distribution of the SE, the ciliated SCs, and the AOO, as the same structure in the sea lamprey Petromyzon marinus (Kleerekoper and Erkel 1960). Among those characters, a tube form of the nostril of L. reissneri are responsible for its habitat, where has a somewhat slow-water currents, being occupied by water plants, gravels and pebbles (Kim and Park 2002; Fig. 1b). The tube form also may be suitable for its ecology that the fish burrows its body into the sand at daytime during the lifetime from the ammocoetes to the adult stage (Kim and Park 2002). Kim et al. (2019) noted that with a contraction and a relaxation of the accessory nasal sac, the tubular nostril helps generate a force to suck water into the olfactory canal. In addition, Cox (2008) opined that the tubular structure assists to reduce thicker “boundary layer” occurring on the snout surface of inactive fishes. The “boundary layer”, generated by a friction when fish swims forward, disturbs to sense external chemical odors and generally is thicker in an inactive fish than fast-swimming fish (Cox 2008). So, tube form on the head of L. reissneri seems to be a morphological adaptation and a positional strategy for the reduction of “boundary layer” and effective olfaction under sandy ground.
Meanwhile, L. reissneri has 19–20 lamellae in number and are different from the sea lamprey P. marinus with 25 (Kleerekoper and Erkel 1960) and other hagfishes, Myxine glutinosa, Eptatretus stoutii and E. deani, with 7 lamellae (Theisen 1976). Generally, in teleost fish, the lamellar number of the olfactory organ is species-specific: absence (Conidens laticephalus of the Order Gobiesociformes, Oryzias latipes and O. sinensis of the Beloniformes, and Periophthalmus modestus, P. magnuspinnatus of the Perciformes), only one (Hemiramphus sajori, Cheilopogon agoo, and Cololabis saira of the order Atheriniformes), up to 120 (Conger myriaster of Anguilliformes) and 230 lamellae (Holopagus guentheri of Perciformes) (Yamamoto 1982; Kasumyan 2004; Kim et al. 2019). It was known that the increase of lamellae leads to the increase of distributional area of olfactory receptor neurons (Kasumyan 2004). Teichmann (1954) also documented that microsmatic catfishes with greater lamellar number show more active response to any chemical stimulant than one with lesser lamellae. At least, the greater number in lamellae of L. reissneri may be more likely to have higher olfactory dependence than other cyclostomata hagfishes with less.
In fish’s olfactory epithelium, it is common that the SE is a simple pseudostratified layer with numerous neurons and the NSE is a stratified squamous layer consisting of stratified epithelial cells (Hara 1986). Interestingly, the SE and NSE of L. reissneri consist of a simple pseudostratified layer, first findings, not reporting in other cyclostomatas and P. marinus. Almost jawed fishes has shown the NSE formed from a stratified squamous layer which has various-shaped cells from columnar or cuboidal types in deeper layer to squamous or flattened types at the surface (Hara 1986; Ghosh and Chakrabarti 2009; Kim et al. 2018, 2019). In contrast, as the NSE of L. reissneri is a histological organization unlike those of the above higher taxa, it may be considered a specific histological character of lamprey belonging to the cyclostomata.
In jawed fishes, the length of olfactory sensory cilia varies by species: 2-3 μm in Daniro rerio (Hansen and Eckart 1998), the maximum 10 μm in Acipenser baeri (Hansen and Zielinski 2005), 10-30 μm similarly in Lota lota L. (Gemne and Døving 1969) and Calamoichthys calabaricus (Schulte and Holl 1971). Further, lampreys show a different length in related congeneric species: 0.2–0.5 μm in L. reissneri (this study) vs. 5–6 μm in L. fluviatilis (Thornhill 1967). Menco (1980) reported that in a comparative study of frog, ox, rat, and dog using a freeze-fracturing the effectiveness of ciliary mechanism to sense external odors is related to the increase of cilia area by number, length, and any attaching component. Twisted ciliary aggregations become packed mat within mucus and then may help make mucus film covering the olfactory surface (Farbman 1992).
Consequently, the anatomy and histology of the olfactory organ of L. reissneri may well reflect its microhabitat where water flows slowly and bottom structure consists of sand, gravels and pebbles, and its ecological habit that fish burrows its body into sandy ground. Among the characters, both 19–20 lamellae and the ORN’s short ciliary length are at least regarded as a useful taxonomic character for lamprey.
The Far Eastern brook lamprey Lethenteron reissneri, the non-parasitic and non-anadromous fish, prefers to live in slow-flowing water in a river or mid-stream, and its adult is a nocturnal fish that hides beneath sand, gravels or pebbles at daytime and act at night. A single gourd-like chamber, a nasal valve, a nasopharyngeal pouch, a longitudinal arrangement of lamellae, and the AOO are general features responsible for primitive vertebrate taxa and may be a morphological adaption for effective sensory activity in such habitat. In particular, 19 to 20 lamellae and a quarter ciliary length (0.2–0.5 μm) of the knob diameter in the ORN may be a useful taxonomic character compared to the sea lamprey P. marinus, and both the SE and NSE of a simple pseudostratified layer may be regarded as a unique histological character, not reported in other cyclostomata.
Availability of data and materials
J.P. Cox, Hydrodynamic aspects of fish olfaction. J. R. Soc. Interface 5, 575–593 (2008)
M.F. Docker, Bill Beamish’s contributions to lamprey research and recent advances in the field. Guelph Ichthyol. Rev. 7, 1–52 (2006)
A.I. Farbman, Cell biology of olfaction, vol 27 (Cambridge University Press, Cambridge, 1992)
S. Ferrando, A. Amaroli, L. Gallus, S. Aicardi, D. Di Blasi, J.S. Christiansen, M. Vacchi, L. Ghigliotti, Secondary folds contribute significantly to the total surface area in the olfactory organ of Chondrichthyes. Front. Physiol. 10, 245 (2019)
G. Gemne, K.B. Døving, Ultrastructural properties of primary olfactory neurons in fish (Lota lota L.). Am. J. Anat. 126, 457–475 (1969)
R.W. Gess, M.I. Coates, B.S. Rubidge, A lamprey from the Devonian period of South Africa. Nature 443, 981–984 (2006)
D. Ghosh, D.K. Mandal, Mercuric chloride induced toxicity responses in the olfactory epithelium of Labeo rohita (HAMILTON): A light and electron microscopy study. Fish Physiol. Biochem. 40, 83–92 (2014)
S.K. Ghosh, P. Chakrabarti, Cellular architecture and functional aspects of the olfactory rosette of Wallago attu (Bleeker). Turk. J. Fish. Aqua. Sci. 9, 187–190 (2009)
G.T. Gurr, A Practical Manual of Medical and Biological Staining Techniques (Interscience, New York, 1956), pp. 1–99
A. Hansen, Z. Eckart, The peripheral olfactory organ of the zebrafish, Danio rerio: an ultrastructural study. Chem. Senses 23, 39–48 (1998)
A. Hansen, B.S. Zielinski, Diversity in the olfactory epithelium of bony fishes: Development, lamellar arrangement, sensory neuron cell types and transduction components. J. Neurocytol. 34, 183–208 (2005)
T.J. Hara, in The behaviour of teleost fishes. Role of olfaction in fish behaviour (Springer, US, 1986), pp. 152–176
M.W. Hardisty, Biology of the Cyclostomes (Springer, NewYork, 2013), p. 428
A.O. Kasumyan, The olfactory system in fish: Structure, function, and role in behavior. J. Ichthyol. 44, 180–223 (2004)
H.T. Kim, Y.J. Lee, J.Y. Park, Functional anatomy and histology of the olfactory organ in Korean eel goby, Odontamblyopus lacepedii (Pisces: Gobiidae). Appl. Micros. 48, 11–16 (2018)
H.T. Kim, S.W. Yun, J.Y. Park, Anatomy, histology, and histochemistry of the olfactory organ of the Korean shuttles mudskipper Periophthalmus modestus. J. Morphol. 280, 1485–1491 (2019)
I.S. Kim, J.Y. Park, JY, Freshwater fishes of Korea (Kyo-Hak Publishing, Seoul, 2002) (in Korean)
H. Kleerekoper, G.V. Erkel, The olfactory apparatus of Petromyzon marinus L. Canadian J. Zool. 38, 209–223 (1960)
B.P.M. Menco, Qualitative and quantitative freeze-fracture studies on olfactory and nasal respiratory structures of frog, ox, rat, and dog. Cell Tissue Res. 207, 183–209 (1980)
T.O. Nilsen, L.O. Ebbesson, S.S. Madsen, S.D. McCormick, E. Andersson, B.T. Björnsson, P. Prunet, S.O. Stefansson, Differential expression of gill Na+, K+-ATPaseα-and β-subunits, Na+, K+, 2Cl-cotransporter and CFTR anion channel in juvenile anadromous and landlocked Atlantic salmon Salmo salar. J. Exp. Biol. 210, 2885–2896 (2007)
I.C. Potter, H.S. Gill, C.B. Renaud, D. Haoucher, in Lampreys: biology, conservation and control. The taxonomy, phylogeny, and distribution of lampreys (Springer, Dordrecht, 2015), pp. 35–73
X. Ren, S. Chang, A. Laframboise, W. Green, R. Dubuc, B. Zielinski, Projections from the accessory olfactory organ into the medial region of the olfactory bulb in the sea lamprey (Petromyzon marinus): A novel vertebrate sensory structure? J. Comp. Neurol. 516, 105–116 (2009)
E. Schulte, A. Holl, Feinstruktur des Riechepithels von Calamoichthys calabaricus JA smith (Pisces, Brachiopterygii). Z. Zellforsch. 120, 261–279 (1971)
H. Teichmann, Vergleichende untersuchungen an der nase der fische. Z. Morphol. Oekol. Tiere 43, 171–212 (1954)
B. Theisen, The olfactory system in the hagfish Myxine glutinosa: I. Fine Structure of the Apical Part of the Olfactory Epithelium. Acta Zool. 54, 271–284 (1973)
B. Theisen, The olfactory system in the Pacific hagfishes Eptatretus stoutii, Eptatretus deani, and Myxine circifrons. Acta Zool. 57, 167–173 (1976)
R.A. Thornhill, The ultrastructure of the olfactory epithelium of the lamprey Lampetra fluviatilis. J. Cell Sci. 2, 591–602 (1967)
J. Van Denbossche, J.G. Seelye, B.S. Zielinski, The morphology of the olfactory epithelium in larval, juvenile and upstream migrant stages of the sea lamprey, Petromyzon marinus. Brain Behav. Evol. 45, 19–24 (1995)
J. Van Denbossche, J.H. Youson, D. Pohlman, E. Wong, B.S. Zielinski, Metamorphosis of the olfactory organ of the sea lamprey (Petromyzon marinus L.): morphological changes and morphometric analysis. J. Morphol. 231, 41–52 (1997)
M. Yamamoto, in Chemoreception in fishes, ed. by T. J. Hara. Comparative morphology of the peripheral olfactory organs in teleosts (Elsevier, Amsterdam, 1982), pp. 39–59
X.U. Yang, Z.H.U. Si-Wei, L.I. Qing-Wei, Lamprey: A model for vertebrate evolutionary research. Zool. Res. 37, 263 (2016)
E. Zeiske, B. Theisen, H. Breucker, in Fish chemoreception, ed. by T. J. Hara. Structure, development, and evolutionary aspects of the peripheral olfactory system (Springer, Netherlands, 1992), pp. 13–39
No funding was received for this work.
The authors declare that they have no competing interests.
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
About this article
Cite this article
Kim, HT., Park, JY. Microscopic research on the olfactory organ of the Far Eastern brook lamprey Lethenteron reissneri (Pisces, Petromyzontidae). Appl. Microsc. 50, 18 (2020). https://doi.org/10.1186/s42649-020-00038-3
